SZJ—7500PE IMM管件参数表
FJ-770SE | ||||
螺杆直径 | 螺杆记号 | Screw Code | mm | 110 |
螺杆长径比 | Screw L/D Ratio | L/D | 26 | |
柱塞直径 | Piston Diameter | mm | 200 | |
理论容积 | Calculated Injection Volume | cm3 | 43960 | |
注射重量 (PE) | Injection Capacity (PE) | g | 31211 | |
注射速率 | Injection Rate (50hz) | g/s | 1103 | |
注射压力 | Injection Pressure | Mpa | 81 | |
螺杆最高转速 | Max. Screw Speed | rpm | 0-90 | |
合模装置 CLAMPING UNIT | ||||
合模力 | Clamping Force | KN | 7500 | |
移模行程 | Clamping Stroke | mm | 980 | |
拉杆内距 | Space Between Tie Bars | mmxmm | 960x960 | |
最大模厚 | Max.Mold Height | mm | 980 | |
最小模厚 | Min.Mold Height | mm | 400 | |
顶出力 | Ejector Force | KN | 200 | |
顶出行程 | Ejector Stroke | mm | 280 | |
顶出杆根数 | Ejector Number | Pc | 21 | |
其它 GENERAL | ||||
最大油泵压力 | Max.Pump Pressure | MPa | 16 | |
油泵马达 | Pump Motor Power | Kw | 40.7*2=81.4 | |
电热功率 | Heater Power | Kw | 138 | |
外形尺寸 | Machine Dimension(LxWxH) | m | 13.5X3.0X2.4 | |
重量 | Machine Weight | t | 48 | |
料斗容积 | Hopper Capacity | Kg | 400 | |
油箱容积 | Oil Tank Capacity | L | 2900 | |
The weight in the table is the theoretical calculation value, and the actual object shall prevail.
The specifications are subject to change without notice
