Description
The price is for reference only！
Product Paramenters
|
SZ-2400A INJECTION UNIT
|
||||||||
|
ITEM
|
UNIT
|
VALUE
|
||||||
|
SCREW DIAMETER
|
mm
|
55
|
60
|
65
|
||||
|
SCREW L/D RATIO
|
L/D
|
22.9
|
21
|
19.4
|
||||
|
Theoretical Shot Volume
|
cm^3
|
665
|
791
|
929
|
||||
|
SHOW WEIGHT(PS)
|
g
|
605
|
720
|
845
|
||||
|
INJECTION PRESSURE
|
Mpa
|
210
|
176
|
150
|
||||
|
THEORETICAL INJECTION RATE(PS)
|
g/s
|
176.5
|
210
|
245
|
||||
|
PLASTICISING CAPACITY
|
g/s
|
26.4
|
32.5
|
40
|
||||
|
SCREW TORQUE
|
N.m
|
2000
|
||||||
|
MAX.SCREW ROTATE SPEED
|
r/min
|
150
|
||||||
|
INJECTION STROKE
|
mm
|
280
|
||||||
|
SZ-2400A CLAMPING UNIT
|
||||
|
ITEM
|
UNIT
|
VALUE
|
||
|
MAX.CLAMPING FORCE
|
KN
|
2400
|
||
|
MAX.OPENING STROKE
|
mm
|
530
|
||
|
SPACE BETWEEN TIE BARS
|
mm
|
555*555
|
||
|
MOULD HEIGHT
|
mm
|
200-570
|
||
|
MAX.DAYLIGHT
|
mm
|
1100
|
||
|
EJECTOR FORCE
|
KN
|
61.5
|
||
|
EJECTOR STROKE
|
mm
|
135
|
||
|
EJECTOR QUANTITY
|
9
|
|||
|
SZ-2400A OTHER
|
||||
|
ITEM
|
UNIT
|
VALUE
|
||
|
PUMP MOTOR POWER
|
KW
|
22
|
||
|
PUMP PRESSURE
|
Mpa
|
16
|
||
|
HEATING POWER
|
KW
|
18.5
|
||
|
HEATING ZONE
|
5
|
|||
|
SIZE
|
m
|
6.2*1.6*2.1
|
||
|
NET WEIGHT
|
t
|
8.0
|
||
|
OIL TANK CAPACITY
|
L
|
440
|
||
|
INTERNATIONAL DESIGNATION
|
2400-1390
|
|||
