Technical Parameter
| ITEM | 单位UNIT | SZ—1300A | ||
| INJECTION UNIT | ||||
| SCREW DIAMETER | mm | 35 | 40 | 45 |
| SCREW LID RATIO | L/D | 24 | 21 | 18.7 |
| THEORETICAL SHOT VOLUME | CM3 | 173 | 226 | 286 |
| SHOT WEIGHT(PS) | g | 158 | 206 | 260 |
| INJECTION PRESSURE | Mpa | 235 | 180 | 142 |
| THEORETICAL INJECTION RATE(PS) | g/s | 110 | 143 | 181 |
| PLASTICISING CAPACITY | g/s | 13.8 | 19.7 | 27.1 |
| SCREW TORQUE | N.m | 740 | ||
| MAX.SCREW ROTATE SPEED | r/min | 250 | ||
| INJECTION STROKE | mm | 180 | ||
| CLAMPING UNIT | ||||
| MAX.CLAMPING FORCE K | KN | 1300 | ||
| MAX.OPENING STROKE | mm | 400 | ||
| SPACE BETWEEN TIE BARS(VxH) | mm | 420×420 | ||
| MOULD HEIGHT (MIN-MAX) | mm | 160-440 | ||
| MAX.DAYLIGHT | mm | 840 | ||
| EJECTOR FORCE | KN | 31.4 | ||
| EJECTOR STROKE | mm | 100 | ||
| EJECTOR QUANTITY | 5 | |||
| OTHER | ||||
| PUMP MOTOR POWER | KW | 13 | ||
| PUMP PRESSURE | Mpa | 16 | ||
| HEATING POWER | KW | 9.2 | ||
| HEATING ZONE | 4 | |||
| SIZE (LxWxH) | m | 4.7×1.25×1.85 | ||
| NET WEIGHT | t | 4.3 | ||
| OIL TANK CAPACITY | L | 360 | ||
| INTERNATIONAL DESIGNATION | 1300—410 | |||
