Description
|
ITEM |
单UNIT |
SZ—3800A |
||
|
INJECTION UNIT |
|
|
||
|
SCREW DIAMETER |
mm |
65 |
70 |
75 |
|
SCREW LID RATIO |
L/D |
22.6 |
21 |
19.6 |
|
THEORETICAL SHOT VOLUME |
CM3 |
1061 |
1231 |
1413 |
|
SHOT WEIGHT(PS) |
g |
966 |
1120 |
1286 |
|
INJECTION PRESSURE |
Mpa |
203 |
175 |
152 |
|
THEORETICAL INJECTION RATE(PS) |
g/s |
308 |
357 |
410 |
|
PLASTICISING CAPACITY |
g/s |
50.6 |
60.5 |
71.5 |
|
SCREW TORQUE |
N.m |
2860 |
||
|
MAX.SCREW ROTATE SPEED |
r/min |
150 |
||
|
INJECTION STROKE |
mm |
320 |
||
|
CLAMPING UNIT |
|
|||
|
MAX.CLAMPING FORCE K |
KN |
3800 |
||
|
MAX.OPENING STROKE |
mm |
680 |
||
|
SPACE BETWEEN TIE BARS |
mm |
680×680 |
||
|
MOULD HEIGHT |
mm |
250-710 |
||
|
MAX.DAYLIGHT |
mm |
1390 |
||
|
EJECTOR FORCE |
KN |
90.7 |
||
|
EJECTOR STROKE |
mm |
170 |
||
|
EJECTOR QUANTITY |
|
13 |
||
|
OTHER |
|
|||
|
PUMP MOTOR POWER |
KW |
37 |
||
|
PUMP PRESSURE |
Mpa |
16 |
||
|
HEATING POWER |
KW |
25 |
||
|
HEATING ZONE |
|
5 |
||
|
SIZE |
m |
6.8×2.0×2.3 |
||
|
NET WEIGHT |
t |
15 |
||
|
OIL TANK CAPACITY |
L |
820 |
||
|
INTERNATIONAL DESIGNATION |
|
3800—2150 |
||
