Description
|
ITEM |
UNIT |
SZ—10000A |
|||
|
INJECTION UNIT |
|
||||
|
SCREW DIAMETER |
mm |
100 |
110 |
120 |
130 |
|
SCREW LID RATIO |
L/D |
24.2 |
22 |
20.2 |
18.6 |
|
THEORETICAL SHOT VOLUME |
CM3 |
4083 |
4941 |
5880 |
6901 |
|
SHOT WEIGHT(PS) |
g |
3715 |
4496 |
5350 |
6280 |
|
INJECTION PRESSURE |
Mpa |
206 |
171 |
143 |
122 |
|
THEORETICAL INJECTION RATE(PS) |
g/s |
695 |
841 |
1001 |
1175 |
|
PLASTICISING CAPACITY |
g/s |
96 |
116 |
130 |
148 |
|
SCREW TORQUE |
N.m |
8690 |
|||
|
MAX.SCREW ROTATE SPEED |
r/min |
110 |
|||
|
INJECTION STROKE |
mm |
520 |
|||
|
CLAMPING UNIT |
|||||
|
MAX.CLAMPING FORCE K |
KN |
10000 |
|||
|
MAX.OPENING STROKE |
mm |
1160 |
|||
|
SPACE BETWEEN TIE BARS |
mm |
1110×1110 |
|||
|
MOULD HEIGHT |
mm |
450-1200 |
|||
|
MAX.DAYLIGHT |
mm |
2360 |
|||
|
EJECTOR FORCE |
KN |
245 |
|||
|
EJECTOR STROKE |
mm |
350 |
|||
|
EJECTOR QUANTITY |
|
21 |
|||
|
OTHER |
|||||
|
PUMP MOTOR POWER |
KW |
90 |
|||
|
PUMP PRESSURE |
Mpa |
16 |
|||
|
HEATING POWER |
KW |
68.45 |
|||
|
HEATING ZONE |
|
6 |
|||
|
SIZE |
m |
12.38×2.8×3.5 |
|||
1: Are you a trading company or a manufactory?
We are a manufactory, we supply the factory price with good
quality, welcome to visit !
2:Do you have QC or any safety standards for your plastic injection
molding machine?
yes,we have established a highly strict quality control department
to guanrantee good quality.
3:Why choose our plastic injection molding machine?
High quality with competitive price
4::How about quality control in your factory?
"Quality is first, Customers are friends".
